Austrogomphus ochraceus

Jade Hunter (Austrogomphus ochraceus)

Inhabits streams, rivers and lakes

© 2011 DECCW, NSW; 2021 Ian Endersby and DragonflyPix.com

• Gomphidae: Key couplet 1 of 47

•
• ● Generally no incomplete antenodal crossvein proximal to Ax1 in any wing
  ● End of abdomen not elongate, mid-dorsal length of abdominal tergum 9 less than 2.3 mm in male, 2.1 mm in female

• Gomphidae: Key couplet 10 of 47

•
• ● Superior anal appendages parallel or divergent, not converging at tips, each bearing a long, curved ventrobasal branch

• Gomphidae: Key couplet 19 of 47

•


• ● Anterior of abdominal segments 3 and 4 with mid-dorsal yellow band, sometimes narrow, or entirely yellow

• Gomphidae: Key couplet 27 of 47

• ○ Abdominal terga 9-10 usually marked with black or chocolate brown
  ○ If yellow or reddish, then tergum 8 substantially black

• Gomphidae: Key couplet 32 of 47

•


• ● Metanepisternum substantially pale
  ● Pterostigma yellow, brown or black, its length more than 3.3 times its maximum width

• Gomphidae: Key couplet 33 of 47

•
• ● Black and yellow or greenish-yellow, lacking lilac colouration
  ● Metepimeron posteriorly not margined with brown

• Gomphidae: Key couplet 35 of 47

•
• ● Antehumeral stripe aslant, isolated or its lower end fused with collar
  ● Black mark on lower mesepimeron extending to level of, or engulfing, metastigma
  ● If not, metapleural suture lined with black

  ⇒ genus: Austrogomphus

• Gomphidae: Key couplet 39 of 47

• ○ Abdominal segment 10 yellow, or black and yellow above

• Gomphidae: Key couplet 42 of 47

•
• ● Antehumeral stripe usually isolated from collar
  ● If fused, a black stripe present along all or most of line of intersegmental suture, interrupted for, at most, a third of length, above metastigma

• Gomphidae: Key couplet 44 of 47

•
• ● Abdominal tergum 8 with basal, mid-dorsal yellow stripe, sometimes short, and lacking basal yellow ring

• Gomphidae: Key couplet 45 of 47

•
• ● Superior appendage of male swollen on upper surface just before tip
  ○ Female occiput unarmed
  ● Vulvar scale narrow, elongate
  ○ [The pterostigma is slightly swollen and usually 'windowed', with a heavy, blackish outer margin and a paler centre, commonly pale brown]

  ⇒ species: Jade Hunter (Austrogomphus ochraceus)
